Data Retrieval

This API provides access to various data sources (incl. TargetData, CDS, and external data systems, CDPs, etc.) using a pipeline to retrieve data for specified fields, for example identifiers, permissions and attributes, as well as the internal and external data sources. Data retrieval from multiple data sources can be combined in a single request.

The pipeline defines what data is returned for each top-level field provided in the request including sub-level fields, for example identifiers of specific name, type and other sub-level fields.

Basic authentication is normally required.

If a client initiated call is required, the pipeline can also use an enrcypted string, for example email, passed in query string parameter for validation of the request.

Request

Request TargetData profile information requires a profile identifier like for example the UMID, which can be retrieved with the FunnelConnect Info call. Any other identifier linked to that profile can be used, for example an encrypted email address.

Server call with basic authentication:

JS
curl -X GET \
  -H 'Authorization: Basic XYZ' \
  https://[domain]/api/v1/[pipeline]/data?attributes&identifiers&permissions&rtNba&cds&out=json&umid=[umid]

Client call with hashed email:

JS
curl -X GET \
  --cookie 'umdid=[umdid]' \
  https://[domain]/api/v1/[pipeline]/data?attributes&identifiers&permissions&rtNba&cds&out=json&encem=[encryptedEmail]

Parameters

Specify the top-level fields you require. Only fields enabled in that pipeline will be returned. Some fields hold more data in sub-level fields. The pipeline configuration will define which of these sub-level fields will be returned.

Name

Type

Description

attributes

Array

Returns an array of attribute objects.

identifiers

Array

Returns an array of identifier objects.

permissions

Array

Returns an array of permission objects.

rtNba

Array

Returns an array of real-time NBA objects.

cds

Array

Returns an array of CDS (Customer Data Store) objects. The “source” field is always provided in the output and has the value “beh_inlining“. In future extensions more elements with different sources might be added to the array. The caller should pick the respective data based on the source. If a field is missing in CDS, it is missing in the output as well. If no profile for the ID was found or all fields are missing, no element is added to the cds array.

out

String

Is used to specify the return message, for example out=json returns a JSON, out=js returns the fcData variable with JSON object.

umid

String

Identifier for the TargetData lookup.

encem

String

Encrypted email used for request authentication.

Response

HTTP Status Codes

Code

Name

Description

200

OK

Successful TargetData lookup. Profile was found and data is returned.

400

Bad Request

The request was malformed. For example an invalid identifier was provided.

401

Unauthorised

Authentication failed.

404

Not Found

Incorrect request method or path or pipeline does not exist.

413

Payload Too Large

The request headers are larger than the configured maximum on the server.

500

Internal Server Error

An error occurred when processing the request. For example the DB access timed out.

Examples

Responses contain either a JSON or JavaSript body, depending on the out-parameter provided in the request.

out=json

JSON
{
  "identifiers": [
    {
      "name": "msisdn-sha2",
      "value": "ea5eb5ce8941948be64a0ef2236a0560f0bbe2a8509d30d7251d96f14ec048a2"
    },
    {
      "name": "umid",
      "value": "87f9e7fe-bcae-48e2-adb8-3dbec4705cf6"
    }
  ],
  "attributes": [
    {
      "name": "dwhPostcode",
      "value": "24787",
      "metadata": {
        "extractDate": "20190928",
        "contractDateEnd": "20210507"
      }
    },
    {
      "name": "device",
      "value": "Apple iPhone 8 (A1905) HSDPA EDGE 3G (GSM/DCS/PCS/LTE)",
      "metadata": {
        "extractDate": "20190928",
        "contractDateEnd": "20210507"
      }
    }
  ],
  "permissions": [
    {
      "name": "LI-OM",
      "value": true,
      "sources": [
        "DWH_IMPORT"
      ],
      "lastUpdated": "2019-05-26T04:09:37Z"
    },
    {
      "name": "LI-NBA",
      "value": true,
      "sources": [
        "WEB"
      ],
      "lastUpdated": "2019-09-28T10:08:25Z"
    }
  ],
  "rtNba": [
    {
      "priority": "1.0",
      "issue": "ACC_Re",
      "cellcode": "4G_SWAP4",
      "campcode": "MCC_3102",
      "group": "ACC_Re_group"
    }
  ],
  "cds": [
    {
      "source": "beh_inlining",
      "product": "red business prime mit premium-smartphone",
      "product_category": "tariff",
      "fixnet_isp": "Deutsche Telekom AG",
      "mobile_isp": "O2 Germany GmbH & Co. OHG"
    }
  ]
}

out=js

JS
var fcData = {
  "identifiers": [
    {
      "name": "msisdn-sha2",
      "value": "ea5eb5ce8941948be64a0ef2236a0560f0bbe2a8509d30d7251d96f14ec048a2"
    },
    {
      "name": "umid",
      "value": "87f9e7fe-bcae-48e2-adb8-3dbec4705cf6"
    }
  ],
  "attributes": [
    {
      "name": "dwhPostcode",
      "value": "24787",
      "metadata": {
        "extractDate": "20190928",
        "contractDateEnd": "20210507"
      }
    },
    {
      "name": "device",
      "value": "Apple iPhone 8 (A1905) HSDPA EDGE 3G (GSM/DCS/PCS/LTE)",
      "metadata": {
        "extractDate": "20190928",
        "contractDateEnd": "20210507"
      }
    }
  ],
  "permissions": [
    {
      "name": "LI-OM",
      "value": true,
      "sources": [
        "DWH_IMPORT"
      ],
      "lastUpdated": "2019-05-26T04:09:37Z"
    },
    {
      "name": "LI-NBA",
      "value": true,
      "sources": [
        "WEB"
      ],
      "lastUpdated": "2019-09-28T10:08:25Z"
    }
  ],
  "rtNba": [
    {
      "priority": "1.0",
      "issue": "ACC_Re",
      "cellcode": "4G_SWAP4",
      "campcode": "MCC_3102",
      "group": "ACC_Re_group"
    }
  ],
  "cds": [
    {
      "source": "beh_inlining",
      "product": "business prime mit premium-smartphone",
      "product_category": "tariff",
      "fixnet_isp": "Deutsche Telekom AG",
      "mobile_isp": "O2 Germany GmbH & Co. OHG"
    }
  ]
};
